LTH MOD53 - Pressure Input Calibration Steps

10 Calibration
62
PRESSURE INPUT CALIBRATION
Pressure In
p
ut
Pressure Input Calibration
Press to begin calibration
Are You Sure?
The instrument will ask for confirmation
Press to Confirm, any of the other 3 buttons
will abandon the sensor calibration.
Set In
p
ut to 4mA
Set the pressure transmitter output to 4mA.
Press “ENTER” to start
Sam
p
lin
g
The unit will sample the 4mA input current.
When complete the display will move on to the 20mA calibration
Set In
p
ut to 20mA
Set the pressure transmitter output to 20mA
Press “ENTER” to start
Sam
p
lin
g
The unit will sample the 20mA input current.
