SET POINT 4
Set Point 4 can be configured as an alarm output triggered by one of a number of
events. This can be configured by editing the SP4 trigger, which can be found after
the Set Point 3 configuration in the “Set Points 3&4” menu.
Set Points 3&4
Set Points 3 & 4 Menu Header
Ø
ØØ
Ø×
××
×
The Set Point 3 menu continues from here and is structured in the same
manner as for Set Points 1 and 2.
Ø
ØØ
Ø×
××
×
Relay 4 will energise only when the selected
state occurs, and de-energise when that
state clears.
SP4: Disabled
Sensor
- When a sensor related error is detected
Dose
- When any of the Dose Alarms activates
Calibration
- When a calibration is in progress
Off-Line
- When the unit is taken “Off-Line”
An
y
Error
- When any system error is detected.
