Lumibird Quantel ABSOLU - Accessories and Consumables; Spare Parts Identification

Service manual
Service Manual – 11 / 63
XE_ABS_MT_AN_200224
PROBES
PCSX0005
15 MHz B Probe including: Probe Holder, Finger Grip Sleeve and Installation Software on USB key
PCSX0007
50 MHz Linear Probe including: 1 Pack of 10 Filmed Windows + 1 Cap, Calibration Tool,
Distilled Water (pack of 5 unidoses), 2 ClearScan, Probe Holder, and Installation Software on USB key
PCSX0009
Biometry Option including: Biometry Probe, Test Bloc and Installation Software on USB Key
PCSX0010
ProBeam™ Option including: Biometry Probe with Laser Aiming Beam, Test Bloc and Installation
Software on USB Key
OPTIONS
PCBX0056
20 MHz Option including:
20 MHz Annular Probe and its ERM Board, Probe Holder, Finger Grip Sleeve, Installation Software on
USB Key
PCBX0037SUP
S Option including:
Standardised A Probe and its ERM Board, Keycode, Tissue Model, Installation Software on USB Key
PCEX0007
DICOM Connectivity
Optional Software to export data to a server in DICOM standard
PCBX0037ABS
ABSolu Console for connection with 15Mhz, 50Mhz and Biometry Probes including:
2 Probe Holders, Footswitch, Protective Cover, Mouse Pad, Clinical Echography of the Eye and Orbit
Monograph, E-User Manual, E-Quick Start, Power Cord
7.2. Accessories and consumables
CODE
ITEM
ACCESSORIES
PCEX0008
Trolley
RM150292A
Probe Holder for B Probes (15Mhz and 20Mhz)
RP160052A
Wireless Keyboard (Azerty) including Mouse
RP160053A
Wireless Keyboard (Qwerty) including Mouse
SC010047A
Finger Grip Sleeve for 15Mhz B Probe
SC010122A
Finger Grip Sleeve for 20Mhz Annular Probe
XEAAACOQLIN14
Scleral Shell 14 mm for Linear Probes
XEAAACOQLIN16
Scleral Shell 16 mm for Linear Probes
XEAAACOQLIN18
Scleral Shell 18 mm for Linear Probes
XEAAACOQPRAEG15
Präger Shell 15 mm for Biometry (children)
XEAAACOQPRAEG17
Präger Shell 17 mm for Biometry (adults)
XEAAAPAM
Extension Handle for Biometry Probe
XEAAAPEDALE4RF
Wireless 4-Position footswitch
XEHUBUSB
USB Hub
XEIMPUSBLASER
USB Laser Printer
XEIMPUSBSONY
USB Sony Video Printer
XELIVRE1
Clinical Echography of the Eye and Orbit Monograph
CONSUMABLES
XEAAAGEL
250 ML Gel for echography
XEPRBFEN2
Filmed windows for 2
nd
Gen 50Mhz Linear Probe (box of 10 pcs)
XEPRBFS
ClearScan for 50MHz Linear Probe - diam. 25 mm (box of 10 pcs)
7.3. Spare parts
CODE
ITEM
SPARE PARTS
SC010119
ABSOLU S-15-50 MHz ERM board
SC010063
ABSOLU A-15-50 MHz ERM board
SC010101
ABSOLU potentiometer cable
RE010090
Power supply module (12V)
RE090266
USB stick
SC010069
Package screen
SC010107
ERM Board for Annular 2MHz probe
