Service Manual – 19 / 63
XE_ABS_MT_AN_200224
8.6. Fuse replacement
WARNINGS & CAUTIONS
Disconnect the power supply before cleaning the unit case.
Only use a damp cloth for cleaning the unit. Do not use any solvent or alcohol.
Disconnect the power cord before any intervention on the unit.
Fuse replacement:
Fuse specifications:
2 glass fuses in the holder
5 AT
Pdc: 50A @ 250VAC
5 x 20 mm
9. ABSOLU DEVICE DISPLAY – Adjust magnifier tool
To ensure that the text in the ABSOLU screen is not truncated, the magnifier tool parameter
has to be adjusted as shown below, and select “Apply”:
