Service Manual – 33 / 63
XE_ABS_MT_AN_200224
Check the probe cable is not in contact with:
o The unit power supply module,
o The unit screen,
o The printer USB cable,
Check the probe cable is straight (not entangled),
Try to switch off the light, air conditioned system, phone… (in the room or in another
room),
Check that the other units installed nearby the unit do not generate noise; if this is the
case: switch off this unit when using the probe.
Check the noise impact of any other peripheral connected to the unit: for example, a
printer
Check that the unit is not connected to the network: disconnect the RJ-45 cable and
check the image again.
Check that the mouse, the keyboard and the dongle do not interfere with the device
(unplug them).
10.6. Probes care
Linear probes storage:
1- Remove and throw away the white removable window.
2- Drain out the water from the probe.
3- Place the black cap on the probe aperture to avoid dust
penetration.
4- Store the probe inside its box.
