Service manual

Service Manual – 16 / 63

XE_ABS_MT_AN_200224

8.4. Open the screen

1/ Unscrew the 10 screws and remove the

back cover.

2/ Remove the metal frame and unscrew the

loudspeaker to have access to the hard

drive and the boards.
