3.3.6 Multi-motor
operation on
one inverter
The CDA3000 inverter modules can be run with several motors config-
ured in parallel. Depending on drive task, various project planning condi-
tions must be met.
L1= Line choke, See section 6.1
L2= Motor choke, See section 6.2
Figure 3.36 Multi-motor operation on one inverter
