1 Analysis of task
1.1 Systematic thinking ................................................1-2
1.1.1 Inverter system ....................................................1-2
1.1.2 System environment ............................................1-3
1.2 Process analysis .....................................................1-4
1.2.1 Example of a process analysis in comparison with
functional analysis ...............................................1-4
1.3 Characteristic values of machinery .......................1-9
1.3.1 Movement requirement ........................................1-9
1.3.2 Moment of inertia ..............................................1-12
1.3.3 Manipulating range and accuracy ......................1-13
1.3.4 Load torque .......................................................1-19
Take your time, especially at
the beginning
Please note: The more complex the task, the more important is the analy-
sis. A “better” analysis can identify impending failures in good time.
"Good" "Better"
Complexity
Complexity
Analysis
Analysis
Intuition/experience
Intuition/experience
Decision
Decision
Time and
cost saving
