CONTROLS, INSTRUMENTS AND EQUIPMENT
fsi2013-010-003_b
Remove the seat by pulling and lifting
atthesametime.
fsi2013-010-005
NOTICE
Pull the handle upwards
when removing the seat.
fsi2013-010-006
Seat Instal lation
Push the seat until you hear a clicking
sound.
fsi2013-010-001
Attach the battery cover back to its
place.
fsi2013-010-002
Finish the installation by locking the
storage / battery compartment cover.
NOTICE
Install the seat first then
push back the storage / battery com-
partment cover to lock the seat prop-
erly in position.
fsi2013-010-003_a
_______________
73
