CONTROLS, INSTRUMENTS AND EQUIPMENT
Engine Coolant Temperature
(Optional Module)
Overheating indicator.
NOTICE
If engine overheats, stop
vehicle in a safe place. Refer to
TROUBLESHOOTING section.
mmo2012-005-095_a
OPTIONAL MODULE INSTALLED
1. Overheating indicator
F) E-TEC Engine Storage Mode
Displays "OIL" when the engine enters
the storage procedure.
12) Multifunction
Analog/Digital Gauge
E-TEC Touring Kit Models with
Multifunction Analog/Digital Gauge
WARNING
Reading the gauge digital display
can distract from the operation of
the vehicle, particularly from con-
stantly scanning the environment.
Gauge Description
mmo2007-009-066_x
MULTIFUNCTIO N AN ALOG/DIGITAL GAUGE
1. Speedometer
2. Tachometer
3. M ultifu nction digital display
4. Pilot lamps
5. Mode button
6. S et button
NOTE: The gauge is factory preset in
metric units but it is possible to change
it to Imperial units, contact an autho-
rized Lynx dealer for unit settings.
1) Speedometer
Measures vehicle speed.
mmo2008-007-017
LH PORTION OF GAUGE
2) Tachometer (RPM)
Measures engine revolution per
minute (RPM). Multiply by 1000 to ob-
tain the actual revolutions.
54
