MacDon M150 2008 - Knife Speed

HEADER OPERATION – A SERIES
Form # 169017 100 Issue – June 2008
6.6.5 Knife Speed
The ideal cutting speed of the knife should be
such that a clean cut is achieved. Crop types
and conditions usually influence the knife and
forward speeds.
The tractor WCM reads a code from the header
that determines the knife speed range and the
minimum speed when the header is first
attached to the tractor. The desired speed can
be programmed on the CDM and is stored in the
WCM memory so that if the header is detached
and then re-attached to the tractor, the knife will
operate at the original set-point.
If no header code is detected, the CDM displays
NO HEADER and the knife speed reverts to a
range from 0-1400 strokes per minute and the
operator can then pre-set the speed.
HEADER
DESCRIPTION
KNIFE SPEED *
(Strokes Per Minute
[SPM])
TYPE SIZE MINIMUM MAXIMUM
Auger A40 All 1400 1950
Auger A30 All 1450 Fixed
* Suggested Overload Setting – 75% of Knife
Speed.
NOTE
The knife speed cannot be programmed
outside the range specified for each
header.
NOTE
The speed can be adjusted without
shutting down the machine, although it is
recommended that the windrower be
stopped to enable the operator to re-
program the WCM.
Display and set knife speed on-the go as
follows:
CAUTION
Check to be sure all bystanders have cleared
the area.
#### = STROKES
PER MIN
HEADER ENGAGED
PRESS
PROGRAM/SELECT
DISPLAY SHOWS
#### KNIFE SPM
DONE
SPEED
O.K.?
NO
YES
ON CDM PRESS
LEFT ARROW o
r
RIGHT ARROW
DISPLAY
SLOWER
FASTER
PROGRAM/SELECT
