SPECIFICATIONS
Form 169017 15 Issue – June 2008
4.2 SPECIFICATIONS
M150 M200
ENGINE
Type Cummins QSB-130 4 Cyl. Turbo Cat C6.6 6 Cyl. Turbo
Displacement 275 cu.in. (4.5 L) 403 cu.in. (6.6 L)
Power
Rated
130 hp (97 kW) @ 2200 rpm 213 hp (159 kW) @ 2200 rpm
Peak
140 hp (104 kW) @ 2000 rpm 220 hp (164 kW) @ 2000 rpm
Bore 4.04 in. (102 mm)
Stroke 5.39 in. (137 mm)
Maximum RPM (no load) 2270-2330 2250-2300
Idle RPM 1100 1100
ELECTRICAL SYSTEM
Recommended Battery (2)
12 Volt, Min. 750CCA, Max Dim – 13.25x7.37 x9.43 in. (337x188x232 mm).
Group Rating 29H or 31A. Heavy Duty/Off Road/Vibration Resistant.
Alternator 130 amp 120 amp
Starter Wet Type
Working Lights 11
TRACTION DRIVE
Type Hydrostatic, 2 Speed Electric Shift Hydrostatic, 3 Speed Electric Shift
Speed
Field (Cab Fwd)
Lo Range 0-11 mph (17.7 km/h)
Lo Range 0-11 mph (17.7 km/h)
Mid Range 0-16 mph (25.7 km/h)
Reverse (Cab Fwd)
6 mph (9.6 km/h)
Transport (Engine Fwd)
High Range 0-23 mph (37 km/h)
Transmission
Type
2 Piston Pumps – 1 per Drive Wheel.
Displacement
2.65 cu.in. (44 cc)
Flow
40 U.S. gpm (151 L/min)
Final Drive
Type
Planetary Gearbox
Ratio
30.06 : 1
Wheel Motor Displ.
Lo Range
4.15 cu.in. (68 cc)
Mid Range
2.93 cu.in. (48 cc)
Hi Range
2.0 cu.in. (33 cc)
SYSTEM CAPACITIES
Fuel Tank
97 U.S. Gallons (378 L)
Cooling
5.1 U.S. Gallons (20 L)
Hydraulic Reservoir
17.2 U.S. Gallons (66 L)
HEADER DRIVE
Type Hydraulic, Load Sensing Variable Displacement
Piston Pumps
Displacement
Pump A – 0-2.75 cu.in. (0-45 cc)
Pump B - 0-2.32 cu.in. (0-38 cc)
Pumps A & B – 0-3.11 cu.in. (0-51 cc)
Flow
Pump A
0-27 U.S. gpm (102 L/min) 0-39 U.S. gpm (148 L/min)
Pump B
0-24 U.S. gpm (91 L/min) 0-34 U.S. gpm (128 L/min)
Max
Pressure
Pump A
4000 psi (27.58 MPa) 4800 psi (33.10 MPa)
Pump B
3200 psi (22.06 MPa) 4800 psi (33.10 MPa)
(continued next page)
