OPERATOR’S STATION
Form 169017 21 Issue – June 2008
5.7.2 Engine Forward Lighting
5.8 WINDSHIELD WIPERS
The windshield wiper controls are located in the
cab headliner. The illustration above right
designates the controls as in the cab forward
mode.
5.9 REAR VIEW MIRRORS
Two adjustable outside mounted mirrors provide
rear view vision when the tractor is operated in
the cab forward mode. A single interior mounted
mirror provides rear view vision in the engine
forward mode.
FRONT WIPER SWITCH
Controls Front Windshield Wiper
ON/OFF
REAR WIPER SWITCH
Controls Rear Windshield Wiper
ON/OFF
REAR VIEW MIRRORS
CAB FORWARD
REAR VIEW MIRROR
ENGINE FORWARD
FRONT – ENG FWD
TURN SIGNALS/HAZARDS - AMBER
HI/LO LIGHTS - ROAD
REAR – ENG FWD
TAIL/BRAKE LIGHTS - RED
TURN SIGNALS/HAZARDS - AMBER
