OPERATOR’S STATION
Form # 169017 24 Issue – June 2008
5.13 RADIOS
5.13.1 AM/FM Radio
A radio is available as optional equipment from
your dealer and a space (A) is provided in the
cab headliner to accommodate the installation.
Two pre-wired speakers (B) have been factory
installed in the headliner. Refer to M150 &
M200 Self-Propelled Windrower Unloading and
Assembly Instruction for radio installation
procedures. Operating instructions are supplied
with the radio.
5.13.2 Antenna Mounting
A roof mounted antenna base for installing a
magnetic antenna is available as an option from
your dealer. Order part #160288, or see
illustration for part dimensions for a “homemade”
version. It accommodates most CB, 2-way radio
and satellite radio antennas.
IMPORTANT
Antenna base can only be installed on the
LH and RH rear cab roof bolts.
REMOVE EXISTING BOLT AND
REINSTALL WITH ANTENNA BASE
A
B
B
11 GA. OR 3.0 mm CQHRS
