OPERATOR’S STATION
Form # 169017 38 Issue – June 2008
5.17.4 Cab Display Module (CDM)
Warnings/Alarms
The CDM displays warnings and sounds alarms
to notify the operator of abnormal windrower
status at startup when the ignition is turned on
and at engine operating speeds above 500 rpm.
5.17.4.1 Engine Warning Lights
WATER IN FUEL
Illuminates Yellow
Service Recommended
CAUTION
Illuminates Yellow
Do Not Operate Engine
Refer to Display Code
DISPLAY
Displays Malfunction Code
Refer to Technical Service Manual
ENGINE PREHEAT
Illuminates Yellow
Wait To Start Engine
STOP
Illuminates Red
Stop Engine Immediately
Automatic Shutdown If Engine Not
Shutdown Manually
Refer to Display Code
