OPERATOR’S STATION
Form 169017 37 Issue – June 2008
MISCELLANEOUS OPERATIONAL INFORMATION
DISPLAY (Upper Line) DESCRIPTION
< LEFT TURN ■
Indicates Left Turn When Is Pressed On
CDM. Engine Forward Mode Only. See Note 1.
■ RIGHT TURN >
Indicates Left Turn When Is Pressed On
CDM. Engine Forward Mode Only. See Note 1.
■ HAZARD ■
Indicates Hazard Warning Lights Are On When
Is Pressed On CDM.
HEADER REVERSE
Header Drive Running In Reverse.
HEADER ENGAGED
Header Drive Engaged.
ROAD GEAR
With Hi Range Selected On Console Switch.
Engine Forward Only. See Note 2.
NOTE: 1. When turn signal light switches are pressed in Cab Forward mode, CDM will display “ENGINE
FORWARD ONLY”.
2. When ground speed range switch is pushed to H range in Cab Forward mode, CDM will display
“RANGE NOT ALLOWED”. M150 only.
