MacDon M150 2008 - Page 38

OPERATOR’S STATION
Form # 169017 36 Issue – June 2008
CAB FORWARD/ENGINE RUNNING/HEADER ENGAGED
ROTARY HEADER
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line) DESCRIPTION
#####.# ENGINE HRS
Total Engine Operating Time.
#####.# HEADER HRS
Total Header Operating Time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (If Metric)
Actual Cutting Rate In Acres (Hectares)/Hour.
###.# SUB ACRES
###.# SUB HECTARES (If Metric)
Area Cut Since Last Reset.
###### TOTAL ACRES
###### TOTAL HECT (If Metric)
Total Area Cut By Machine.
#### DISC RPM
##.## REEL SENSOR
(If Sensor Disabled)
Disc Rotational Speed.
##.# HEADER HEIGHT
##.# HEADER SENSOR (If Sensor Disabled)
Distance Setting (00.0-10.0) Between Cutterbar &
Ground.
##.# HEADER ANGLE
##.# HEADER SENSOR (If Sensor Disabled)
Angle Setting (00.0-10.0) Header Relative To
Ground.
##.# L FLOAT R ##.#
Left And Right Float Setting (0.0-9.9).
LOAD|■■■■■■■■■■■■
Bar Graph Representing Hydraulic Operating
Pressure. If sensor disabled, LOAD does not display.
##.# VOLTS
Engine Electrical System Operating Voltage.
SCROLL (Lower Line)
Displays Sub-Menu After 2-3 Seconds. Press
SELECT to cancel.
(Scroll Through Sub-Menu Display with CDM Switch)
SCROLL SUB-MENU (Lower Line Only)
#### DISC RPM
##.# HEADER HEIGHT
LOAD|■■■■■■■■■■■■
DISC SPD OVERLOAD (Lower Line)
Disc Speed Is Less Than Programmed Set-Point.
