MAINTENANCE/SERVICE – M200 ENGINE
Form # 169017 146 Issue – June 2008
j. Clean gasket mating surface.
k. Apply a thin film of clean oil to the gasket on the
new filter.
l. Screw the new filter onto the filter mount until
the gasket contacts the filter head.
m. Tighten the filter an additional ½ to ¾ turn by
hand.
IMPORTANT
Do not use a filter wrench to install the oil
filter. Over-tightening can damage the
gasket and filter.
n. Install the oil pan drain plug (B).
o. Remove oil filler pipe cap (E) and add engine oil.
The engine requires 15.8 U.S. quarts (15 litres)
of SAE 15W40 Compliant with SAE Specs for
API Class CH-4 and C1-4 Engine Oil.
p. Replace filler cap.
q. Operate the engine at low idle and check for
leaks at the filter and drain plug.
r. Stop the engine, wait 5 minutes and check the
oil level. Add or remove oil to bring oil to HIGH
level mark on dipstick.
s. Close engine compartment hood.
t. Properly dispose of used oil and filter.
E
B
