WINDROWER TRACTOR OPERATION
Form 169017 51 Issue – June 2008
6.3.2.2 Windrower
IMPORTANT
Until you become familiar with the sound
and feel of your new windrower, be extra
alert and attentive.
DANGER
Before investigating an unusual sound or
attempting to correct a problem, place GSL
in N-DETENT, shut off engine, and remove
key.
Perform the checks and service in the following
table after the indicated hours of operation.
Refer to the specific section under reference for
service procedures:
WINDROWER BREAK-IN INSPECTION REQUIREMENTS
HRS ITEM CHECK REF.
.25 Road or
1 in Field
Drive Wheel Nuts
Torque – 175-200 ft-lbf (237-271 N· m)
Repeat Checks Until Torque Stabilizes.
7.14.1
5
A/C Belt Tension 7.10.10.1
Caster Wheel Nuts Torque – 115-127 ft-lbf (156-172 N·m) 7.14.2
Caster Wheel Anti-Shimmy
Dampener Bolts
Inboard Bolt Torque – 100 ft-lbf (135 N·m).
Outboard Bolt Torque – 100 ft-lbf (135 N·m)
Walking Beam Width Adjustment
Bolts
Torque – 330 ft-lbf (448 N·m)
6.3.7
10
Walking Beam Width Adjustment
Bolts
Torque – 330 ft-lbf (448 N·m)
Drive Wheel Nuts Torque – 175-200 ft-lbf (237-271 N· m)
Repeat Checks at 20 and 30 hours.
7.14.1
Neutral Dealer Adjust -
50
Hose Clamps – Air
Intake/Radiator/Heater/Hydraulic
Hand Tighten Unless Otherwise Noted. 7.9.5,
7.9.7,
7.10.4,
7.10.7 &
7.13
Walking Beam Width Adjustment
Bolts
Torque – 330 ft-lbf (448 N·m) 6.3.7
Caster Wheel Anti-Shimmy
Dampener Bolts
Inboard Bolt Torque – 100 ft-lbf (135 N·m).
Outboard Bolt Torque – 100 ft-lbf (135 N·m)
7.14.2
Drive Wheel Nuts
Torque 175-200 ft-lbf (237-271 N·m)
Repeat Checks Until Torque Stabilizes.
7.14.1
Drive Wheel Lubricant Change 7.14.1.3
Main Gearbox Oil Change 7.9.8 &
7.10.8
Hydraulic Oil Filters Change 7.13.4
To Next Page
