39
57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
2.7.4 HART Menu – Model 706
1 Enter Password
2 Level Units
3 Probe Model
4 Probe Coating
5 Probe Mount
6 Probe Length
7 Measurement Type
8 Level Offset
9 Dielectric Range
10 Upper Dielectric
11 Basic Config Diagram
1 PV
2 PV Loop Current
3 PV % Range
4 Device Setup
5 Setup Wizard
6 Diagnostics
7 Measured Values
1 Level
2 Ifc Level
3 Upr Thickness
4 Volume
5 Flow
6 Head
7 Distance
8 R Totalizer Value
9 NR Totalizer Value
10 Echo Strength
11 Ifc Echo Strength
12 Buildup
13 Temperature
1 Identity
2 Basic Config
3 Volume Config
4 Flow Config
5 I/O Config
6 Local Display Config
7 Advanced Config
8 Factory Config
1 Enter Password
2 PV is
3 PV AmA Set Point
4 PV 20mA Set Point
5 PV Failure Alarm
6 Damping
7 I/O Config Diagram
8 Variable Selection
9 Set Points
1 Enter Password
2 Flow Units
3 Flow Element
4 Flume Channel Width
5 V-Notch Angle
6 Crest Length
7 Custom Table Type
8 Reference Distance
9 Maximum Head
10 Maximum Flow
11 Low Flow Cutoff
12 General Equation
Factors
13 Flow Diagrams
14 Custom Table
15 Totalizer Setup
1 Manufacturer
2 Product Name
3 Magnetrol S/N
4 Hardware Version
5 Firmware Version
6 ConfigChg Counter
7 Final Assy Number
8 Device ID
9 Universal Revision
10 Field Device Revision
11 Software Revision
12 Num Preambles
1 Enter Password
2 Volume Units
3 Vessel Type
4 Length
5 Width
6 Radius
7 Ellipse Depth
8 Conical Height
9 Table Type
10 Vessel Diagrams
11 Custom Table Type
12 Level Input Source
13 Custom Table Length
14 Custom Table
1 K
2 L
3 C
4 n
1 Totalizer Units
2 NR Mult
3 NR Totalizer Value
4 NR Totalizer RunTime
5 R Totalizer Mode
6 R Totalizer Mult
7 R Totalizer Value
8 R Totalizer RunTime
9 Totalizer
1 SV is
2 TV is
3 QV is
1 Lvl 4mA Set Point
2 Lvl 20mA Set Point
3 Ifc 4mA Set Point
4 Ifc 20mA Set Point
5 Thk 4mA Set Point
6 Thk 20mA Set Point
7 Vol 4mA Set Point
8 Vol 20mA Set Point
9 Flo 4mA Set Point
10 Flo 20mA Set Point
1 Enter Password
2 Tag
3 Long Tag
4 Descriptor
5 Date
6 Message
7 Date/Time/Initials
8 Factory Identity
