57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
2.7.4 HART Menu – Model 706
1 Level Threshold Mode
2 Level Threshold Value
3 Sloped Start Value
4 Sloped End Distance
5 Interface Level Threshold Mode
6 Interface Level Threshold Value
7 EOP Threshold Mode
8 EOP Threshold Value
1 Compensation Mode
2 Vapor Dielectric
1 Identity
2 Basic Config
3 Volume Config
4 Flow Config
5 I/O Config
6 Local Display
Config
7 Advanced Config
8 Factory Config
1 Probe Target Mode
2 Target Calib
3 Target Ticks
4 Auto Target Calib
1 EOP Polarity
2 EOP Analysis
3 EOP Dielectric
1 Enter Password
2 Sensitivity
3 Blocking Distance
4 Safety Zone Settings
5 Failure Alarm Delay
6 Level Trim
7 Adv Config Diagram
8 Echo Rejection
9 Threshold Settings
10 End-of-Probe Settings
11 Compensation
12 HF Cable Length
13 Buildup Detection
14 Analog Output
15 New User Password
16 Reset Paramaters
1 Enter Password
2 Fiducial Gain
3 Fid Thresh Value
4 Probe Target
5 Elec Temp Offset
6 Ifc Boundary Offset
7 NAPValue
8 Factory Reset
9 Factory Param 2
1 Safety Zone Alarm
2 Safety Zone Height
3 Reset SZ Alarm
1 Enter Password
2 Language
3 Status Symbol
4 Long Tag
5 PV Bar Graph
6 Display Setup Diagram
7 Measured Values
1 Reject Curve State
2 Reject Curve Mode
3 Saved Media Location
4 New Rejection Curve
1 Poll Address
2 Analog Output Mode
3 Fixed Loop Current
4 Adjust Analog Output
5 4mA Trim Value
6 20mA Trim Value
7 Fdbk 4mA Trim Value
8 Fdbk 20mA Trim Value
1 Window
2 Fiducial Ticks
3 Conversion Factor
4 Scale Offset
5 7YK Scale Offset
10 Factory Param 3
11 Factory Param 4
12 Factory Calib
