57-606 ECLIPSE Model 706 Guided Wave Radar Transmitter
2.7.4 HART Menu – Model 706
1 PV
2 PV Loop Current
3 PV % Range
4 Device Setup
5 Setup Wizard
6 Diagnostics
7 Measured Values
1 Present Status
2 Event History
3 Advanced
Diagnostics
4 Echo Curves
5 Echo History
6 Trend Data
1 NE107 Category
2 NE107 Highest Active Indicator
3 Add’l Device Status
4 Reset Config Changed
5 NAMUR NE 107 Setup
6 NE 107 Simulation Mode
7 Enter Password
1 NE 107 Mapping
2 Reset NE 107 Mapping
1 Event Log
2 Refresh History
3 Reset History
4 Set Clock
1 Internal Values
2 Elec Temperatures
3 Transmitter Tests
4 Probe Buildup
1 Status 0
2 Status 1
3 Status 2
4 Status 3
5 Status 4
6 Status 5
1 Fiducial Ticks
2 Fiducial Strength
3 Level Ticks
4 Echo Strength
5 Distance
6 Ifc Ticks
7 Ifc Echo Strength
8 Ifc Boundary
9 Ifc Medium
10 Targ Calib Ticks
11 Target Ticks
12 Target Strength
13 Vapor Apparent Diel
14 EoP Ticks
15 EoP Strength
16 EoP Distance (mm)
17 EoP Apparent Diel
18 Fdbk Current
1 Present Temperature
2 Max Temperature
3 Min Temperature
4 Reset Min/Max Temps
1 Analog OutputTest
1 Percent of Level Threshold
2 Buildup Location
3 Buildup Rate
4 Check
