Advanced features Chapter 9
Mastersizer 2000 Page 9-13
To set a Diameter alarm in an SOP measurement:
1. Select the Measurement dialogue.
2. Select the Alarms button in the Advanced options section.
3. On the Diameter alarms tab, enable a percentile alarm by selecting the rele-
vant Enable check box.
4. Set the upper and lower size limits for the alarm by changing the values within
the Lower limit and Upper limit boxes.
5. Click OK.
Averaging records
It is possible to create an average record from several records (usually repeats of the
same sample). Select multiple records by using the CTRL or Shift keys, then
select Edit-Create average result.
A dialogue will appear that will give the user the opportunity to enter a sample
name and the record numbers that were used to create the average. The average
will be created as a separate new measurement record capable of being saved and
recalled.
MAN0384-1.0 Mastersizer 2000.book Page 13 Tuesday, March 20, 2007 8:56 AM
