Chapter 3 Identifying the features
Page 3-8 MAN 0384
Software
The Malvern software controls the system during a measurement and processes the
measurement data to produce a size distribution. There are two software modules:
The main application, described below. This main interface allows the user to
define an SOP, run a measurement, display the results and print reports.
A secondary module, the Report Designer, allows the user to create custom
reports to display the results. The Report Designer is detailed in Chapter 5.
Features of the window
The features of the window are detailed below:
ill 7752
Menu bar
The menu bar contains the main menu headings for all software functions. There
are several ways to select an item from the menu bar:
Using the mouse – to select an item from the menu bar, click the left mouse
button once on the menu. When the menu list drops down, select an item
from the menu list by clicking once on it.
1 2
3
4 5
MAN0384-1.0 Mastersizer 2000.book Page 8 Tuesday, March 20, 2007 8:56 AM
