Mastersizer 2000 Page 5-1
5
Viewing the results
Introduction
Once the result has been calculated, the data can be displayed in many forms. Each
way of displaying the data is known as a report. Each type of report has a tab in the
Measurement window; to view the data in another report simply select the
appropriate tab.
This chapter covers:
Displaying the information – the reports provided and the use of the Records
tab.
Using the Report Designer to create custom reports.
Note
All the tabs in a Measurement window display the same measurement
data but in different formats.
Malvern provides several default reports, identified by the “(M)” in their name, that
will be sufficient for most users. The user can also create their own custom reports
as required.
Generally a computer monitor displays information in a landscape format while a
printer prints in a portrait format. Therefore, each report is split into two formats-
one for displaying the report on the screen, and another configured for a printer. It
is possible for the screen and print formats to be configured to report different
information.
A report file has the extension .pag. The file holds both the screen and print varia-
tions.
Chapter 6 gives details on interpreting the information in a report.
MAN0384-1.0 Mastersizer 2000.book Page 1 Tuesday, March 20, 2007 8:56 AM
