Addendum 0070-2.0 Page 1
Addendum to manual
Addendum number ADD0070-2.0
Date 10/03/2010
Manual number MAN0384-1.0
Manual name Mastersizer 2000 User Manual
This addendum presents new information on the Mastersizer 2000/2000E from
Malvern Instruments.
Laser specification
The following information adds to the Light Sources information given on page
A-1:
Red light
 CDRH and CE compliant (Class llla laser product (CDRH) / Class 3R laser
product (IEC60825-1(1993)+A1(1997)+A2(2001))
 Type: HeNe gas laser.
 Max. output power: 4mW.
 Beam diameter: 0.63mm (1/e²).
 Beam divergence: 1.5mrad.
 Beam wavelength: 633nm.
Blue Light
For the Mastersizer 2000 and Mastersizer 2000LF this is:
 Beam wavelength: 466nm.
 Type: LED.
