Removing and installing power take-off for hydraulic pump
141
Fig. 5
Use ring spanner (special tool) to remove mount-
ing bolt from drive gear.
Caution:
The bolt must not fall into the engine.
Fig. 6
Take off drive gear and pull out bearing flange with
drive shaft.
Installing power take-off for hydraulic
pump
Fig. 7
Insert bearing flange with drive shaft into flywheel
housing (oil O-ring lightly).
Fig. 8
Tighten the drive gear with the prescribed torque.
In doing so, block the drive shaft to prevent it turn-
ing.
Clean gasket residues from the sealing surface of
the gear case cover.
Screw on both covers with new seals.
Fit all removed components.
Caution:
Unblock the crank gear!
