Limit values
Service Data
Dimensions
161
Valve gear
Rocker arm bearing pedestal
24,967−24,980 mm
Kipphebel
Rocker arm radial clearance: 0,025−0,054
mm
Wear limit: 0,08 mm
25,005−25,021 mm
Valve clearance
Valve clearance (cold engine)
Intake valve: 0,5 mm
Exhaust valve: 0,5 mm
14
Ø
