Changing oil filter
61
Caution:
Old oil and used oil filters are hazardous
waste.
Observe safety instructions for the pre-
vention of environmental damage.
Fig. 1
Open oil drain plug and use container to catch oil
that may emerge.
Danger:
Oil filter can and oil filter are filled with hot
oil.
Risk of burns and scalds.
Fig. 2
Remove mounting bolt of the relevant filter bowl.
Remove filter cup and clean inside.
Fig. 3
Insert a new filter cartridge and fit the filter cup
with new gaskets.
Tightening torque: 50 Nm
Insert new filter element and fit filter bowl with new
seals.
Note:
To avoid twisting the gasket, hold the filter
cup while tightening the tensioning screw.
Fill engine oil and check for leaks after a short en-
gine run
Check oil level.
