3
1
Ø
8 mm
8 mm
2
ba
a
Ø 0,02 a
Limit values
Service Data
Dimensions
157
Conrods
46,05546,065 mm
Wear limit: 46,06 mm
Bearing bore in measuring directions 1, 2
and 3 and in measuring planes a and b:
90,07590,120 mm
Edge condition:
New conrod bearing in place, conrod as-
sembled
Conrod bearings
Standard size: 2.4632.473 mm
undersize 0.25: 2.5882.598 mm
undersize 0.50: 2.7132.723 mm
undersize 0.75: 2.8382.848 mm
undersize 1.00: 2,9632,973 mm
Spread: 0,61,5 mm
If signs of wear are present
(scores,antiwaer coating damaged),
change both bearing shells
Important: Observe installation position
(rod shell has red colour markings on the
side)
