Limit values
Service Data
Dimensions
162
Camshaft
Replace if there are traces of wear
Camshaft axial clearance: 0,200,90 mm
Wear limit: 1,5 mm
69,91069,940 mm
Backlash:
Crankshaft wheel and camshaft wheel:
0,118 mm0,242 mm
Camshaft bearing
70,00070,030 mm or
70,07070,090 mm for bush 5 (V8),
6 (V10) or 7 (V12) = bush at timing case
end
Valve tapped
Bore in crankcase:
20,00020,021 mm
19,94419,965 mm
