Engine views
19
À Heat exchanger and coolant surge tank
Á Coolant filler neck
 Relief valve on coolant surge tank
à Intercooler
Ä Oil filler neck
Å Crankcase breather
Æ Air filter
Ç Turbocharger
È Exhaust manifold
É Starter
11
Oil pan
12
Engine cranking device
13
Alternator
14
Coolant pump
15
Oil drain plug
16
Oil dip stick
17
Oil cooler
17
Oil filter
