Removing and installing, repairing 3−gear−oil pump
70
Filling with engine oil
Figs. 12 and 13
Caution:
Do not add so much engine oil that the oil
level rises above the max. marking on the
dipstick. Overfilling will result in damage to
the engine.
Refill with fresh engine oil at the oil filler neck
(arrow).
After filling start the engine and let it run for a few
minutes at low speed.
Caution:
If no oil pressure builds up after approx. 10
seconds switch off the engine immediately.
Check oil pressure and check that there is no oil
leakage.
Then shut down the engine. After about 20 min-
utes, check the oil level.
D Pull out dipstick (arrow)
D wipe it with a clean, lint−free cloth
D and push it in again up to the stop
D Pull out dipstick again
The oil level should be between the two notches in
the dipstick and must never fall below the lower
notch. Top up oil as necessary. Do not overfill.
