Published 3-30-2018, CTRL 636-05 8-3
CD15 OPERATOR MANUAL SPECIFICATION
Lubrication Symbols
Lubrication Legend
Lube Symbol Description Grove Spec
EP-MPG EP-MPG- Multipurpose Grease A6-829-003477
AFC AFC- Anti-freeze/coolant A6-829-101130
HYDO Hydraulic Oil A6-829-006444
HTF Hydraulic Transmission Fluid 80057784
EO-15W-40 Engine Oil Tier 3 A6-829-003483
EO-15W-40 Engine Oil Tier 4 A6-829-104182
EO-10W-30 Engine Oil Dual Fuel A6-829-003480
ASC Anti-Seize Compound A6-829-003689
EP-OGL Open Gear Lube (Ceplattyn 300 Spray) A6-829-102971
EPGL-5 EPGL-Gear Lubricant A6-829-003479
TransSynd Synthetic Transmission Fluid A6-829-101690
Item Location Nam Capacity Lube Symbol Instruction
Front Drive/steer Axle
1 Differential 16.0 L (4.2 gal) HYDO
2 Planetary Hub Gears 2.0 L (2.1 qt) HYDO
3 Kingpin Bearings EP-MPG
4 Steer Cylinder Bearing EP-MPG
5 Universal Joints EP-MPG
6 Brake Caliper EP-MPG
Rear Drive/Steer Axle
7 Differential 18.0 L (4.8 gal) HYDO See Note 1
8 Planetary Hub Gears 2.0 L (2.1 qt) HYDO
9 Hub Bearings EP-MPG
10 Kingpin Bearings EP-MPG
11 Steer Linkage Bearing EP-MPG
12 Steering Cylinder EP-MPG
Engine & Trans.
13 Engine Crankcase Tier 3 and 4 5.5-7.0 L (5.8-7.4 qt) EO-15W-40 See Note 2
13 Engine Crankcase KEM-4.3L Dual Fuel 4.3 L (4.5 qt) EO-10W-30 See Note 2
14 Engine Coolant Tier 3 22.8 L (6.0 gal) AFC See Notes 2, 3, 4
14 Engine Coolant Tier 4 20.0 L (5.3 gal) AFC See Notes 2, 3, 4
14 Engine Coolant KEM-4.3L Dual Fuel 16.3 L (4.3 gal) AFC See Notes 2, 3, 4
15 Transmission 4 Wheel Drive 20.8 L (5.5 gal) HTF
15 Transmission 2 Wheel Drive 16.6 L (4.4 gal) HYDO
