Manitowoc CD15

MAINTENANCE CD15 OPERATOR MANUAL
6-8 Published 3-30-2018, CTRL 636-05
Lubrication Points
Apply grease to the following fittings after the first 20 hours of operation. Thereafter every 50 hours of operation. Use a Lithium
Based, EP2 grease, or equivalent. Apply enough grease to remove the old grease.
Boom and Main Frame
Location QTY
Turntable Bearing (Figure 6-1) 2
Boom Head Sheaves (Figure 6-2) 2
Boom Extend Sheave (Figure 6-2) 1
Drive Train
Location QTY
Steering Knuckles (Figure 6-6) 2 Each Knuckle
Steering Link (Figure 6-6) 2 each Link
Steering Cylinder Pivot Pins (Figure 6-6) 2 each Cylinder
Rear Axle Pivot Pin (Figure 6-6) 2
Optional Equipment and Accessories
Location QTY
Hook Block (see Figure 6-3) As Required (if equipped)
Boom Extension Sheave (see Figure 6-4) 1
Boom Extension Deflector Sheave (see Figure 6-5) 1
Anti-Two-Block Bracket Guide Pins (Figure 6-2) 2 (coat with anti-seize compound)
