CD15 OPERATOR MANUAL SPECIFICATION
8
Hydraulic Tank...................................................................................................130.6 L (34.5 gal), steel construction with
internal baffle
Mast
Rotation.............................................................................................................360°
Mast Bearing (Diameter) ...................................................................................860.65 mm (33.884 in)
Swing Drive Mechanism....................................................................................Hydraulic motor driven gearbox
Swing Speed .....................................................................................................2.1 rpm
Outriggers
Type .................................................................................................................Hydraulic Cylinder each Corner
Construction......................................................................................................Oblique, Welded box
Tires
Size ...................................................................................................................385/65 D22.5
Air pressure.......................................................................................................9 bar (125 psi)
Wheel nut torque...............................................................................................500 ft-lb (680 Nm)
Travel Speeds (approximate)
2-Wheel Drive, Two-Wheel Steer
1st gear forward ...............................................................................................4.0 km/hr (2.5 mph)
2nd gear forward ..............................................................................................8.9 km/hr (5.5 mph)
3rd gear forward ...............................................................................................17.7 km/hr (11 mph)
4th gear forward ................................................................................................27.0 km/hr (16.8 mph)
1st gear reverse ................................................................................................4.0 km/hr (2.5 mph)
2nd gear reverse ...............................................................................................8.7 km/hr (5.4 mph)
3rd gear reverse................................................................................................17.2 km/hr (10.7 mph)
Weight (GVW)
Two Wheel Drive, 41’ Boom, 15’ Extension, Downhaul Weight, Hook Block, Enclosed Operator’s Cab with A/C, and Driver:
with T4 Engine ..................................................................................................11,771 kg (25,950 lbs)
with Tier 3 Engine..............................................................................................11,673 kg (25,735 lbs)
with Dual Fuel Engine .......................................................................................11,609 kg (25,594 lb)
Wire Rope
Main Hoist:
Size ...................................................................................................................14 mm (9/16 in) 6 x 19 XXIPS-IWRC
Length (for all boom lengths) ............................................................................97.5 m (320 ft)
Line Pull ............................................................................................................3856 kg (8,500 lb)
Optional Below Deck Winch:
Diameter ...........................................................................................................11.1 mm (7/16 in)
Length ...............................................................................................................35.1 m (115 ft)
Max Working Load ............................................................................................4536 kg (10,000 lb)
