SPECIFICATION CD15 OPERATOR MANUAL
8-4 Published 3-30-2018, CTRL 636-05
Lubrication Notes
1 4 wheel drive option only.
2 Adjust final fluid levels using dipsticks, level gauges,
markings, or filler plugs.
3 Use a mixture of 50% AFC and 50% water.
4 Engine coolant capacity listed is the combined capacity
for coolant in the engine and radiator.
5 Apply to pins prior to assembly.
6 Lubricate all surfaces in contact with wear pads.
7 Apply to all sides.
8 Make sure hydraulic oil meets or exceed Grove
cleanliness spec 6829014631;
9 Oil or grease all points requiring periodic lubrication as
required during assembly.
10 Lubricate all movable control links and clevis pins during
assembly.
Turntable
16 Swing Gear Box EP-MPG
17 Swing Gear & Pinion EP-OGL
18 Turntable Bearing EP-MPG
Cylinders
19 Outrigger Cylinder Pins ASC See Note 5
20 Boom Lift Cylinder Pins ASC See Note 5
Boom
21 Boom Nose Sheaves EP-MPG
22 Boom Extension Sheaves EP-MPG
23 Boom Sections EP-MPG See Note 6
24 Telescope Cylinder Wear Pads EP-MPG
25 Boom Extend Sheave EP-MPG
26 Boom Retract Sheave EP-MPG
27 Hook Block Swivel Bearing EP-MPG
28 Boom Pivot Pin ASC See Note 5
29 Hook Block Sheaves EP-MPG
Outriggers
30 Outrigger Box EP-MPG See Note 7
Hoist
31 Hoist Gearbox 1 L (1 qt) EPGL-5
32 Hoist Brake 0.24 L (0.25 qt) TranSynd
33 Not Used
Misc.
34 Driveline Joints EP-MPG
35 Fuel Tank 104.4 L (27.6 gal)
36 Hydraulic Tank 130.6 L (34.5 gal) HYDO See Notes 2 & 8
Item Location Nam Capacity Lube Symbol Instruction
