Published 3-30-2018, CTRL 636-05 3-9
CD15 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
To operate the defroster fan, use the switch located on the
instrument panel (see Figure 3-5). Select the desired fan
speed.
NOTE: Be sure the shut-off valve in the hot water supply
line is open. The shut-off valve is located on the
engine.
Fire Extinguisher
The fire extinguisher is located in the cab behind the
operator’s seat (Figure 3-16). Study the manufacturer’s
instructions printed on the fire extinguisher for its proper use.
8910
Heater and A/C Controls
FIGURE 3-14
Louvers
8809
Defroster Fan
FIGURE 3-15
The crane is equipped with a fire extinguisher. Maintain a
charged fire extinguisher AND KNOW HOW TO USE IT.
FIGURE 3-16
