Turntable Bearing Lubrication
Two Fittings, 90° Apart Located on Inside Surface of Bearing
FIGURE 6-1
8929
FIGURE 6-2
8930
Boom Head Sheave Lubrication
Boom Extend
Sheaves Lubrication
Boom Slides Lubrication
(see page 6-15
Anti-Two-Block Bracket
Guide Pin Lubrication
FIGURE 6-3
Hook Block
Lubrication
8921
8931
FIGURE 6-4
Boom Extension
Sheave Lubrication
FIGURE 6-5
8995
Boom Extension Deflector Sheave Lubrication
