Published 3-30-2018, CTRL 636-05 3-23
CD15 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Extend Boom - push forward
Retract Boom - pull backward
FIGURE 3-29
EXTREND
BOOM
RETRACT
BOOM
