Manitowoc CD15 User Manual

ATTACHMENTS CD15 OPERATOR MANUAL
5-4 Published 3-30-2018, CTRL 636-05
FIGURE 5-4
2
1
3
4
5
6
8
7
9
10
11
8923
Boom Extension (Jib) Decal
1 Boom Head
2 Boom Extension
3 Pin with Hair-Pin Cotters (qty 4)
4 Electric Cable from Boom Extension
5 Electric Cable on Boom Head
6 Plug on Boom Head
7 Hoist Wire Rope
8 Rope Retention Pin (qty 3)
9 Deflector Sheave
1
2
3
8
8
7
5
6
4
VIEW A
VIEW B
9
8927
8926
