Manitowoc GROVE GMK 5095 User Manual

Additional pages GMK 4100-L 3 112 557 en 3
26.09.2008
10 m (33 ft) swing-
away lattice
All the axle loads in the following table are valid for a 20 t hook block
(weight: 300 kg (660 lbs)) reeved on the lattice extension.
1)
,
2)
à Table footnotes, p. 2
Counter-
weight
in t
(lbs)
Telescoping
Telescopic section
I-II-III-IV-V-VI
Main
boom
angle
(°)
Lattice
exten-
sion incli-
nation
(°)
Main
boom
position
1)
Maximum axle load
2)
in t
(x 1000 lbs)
front rear
12,9
(28 400)
0.5–0.5–0.5–0–0–0 40 – 50 0 – 40 front
15,5
(34,2)
18,5
(40,8)
0–0–0–0–0–0 78 – 80 0 – 40 rear
11,0
(24,2)
18,5
(40,8)
15,1
(33 200)
0.5–0.5–0.5–0–0–0 40 – 45 0 – 40 front
13,5
(29,7)
19,0
(41,9)
0–0–0–0–0–0 75 – 80 0 – 40 rear
12,5
(27,5)
19,5
(43,0)
17,3
(38 100)
0.5–0.5–0.5–0–0–0 20 – 45 0 – 20 front
19,0
(41,9)
19,0
(41,9)
0–0–0–0–0–0 75 – 80 0 – 40 rear
13,0
(28,6)
19,5
(43,0)
19,5
(42 900)
0.5–0.5–0.5–0–0–0 20 – 30 0 – 20 front
17,5
(38,6)
17,5
(38,6)
0–0–0–0–0–0 75 – 80 0 – 40 rear
14,5
(32,0)
19,5
(43,0)
21,7
(47 800)
0.5–0.5–0.5–0–0–0 20 – 30 0 – 20 front
15,5
(34,2)
20,5
(45,2)
0–0–0–0–0–0 70 – 80 0 – 40 rear
15,5
(34,2)
21,5
(47,4)
23,9
(52 600)
0.5–0.5–0.5–0–0–0 20 – 25 0 – 20 front
13,5
(29,7)
21,5
(47,4)
0–0–0–0–0–0 70 – 80 0 – 40 rear
16,5
(36,4)
21,5
(47,4)
26,1
(57 500)
0.5–0.5–0.5–0–0–0 5 – 20 0 front
14,0
(30,8)
23,0
(50,7)
0–0–0–0–0–0 70 – 80 0 – 40 rear
17,5
(38,6)
21,5
(47,4)
