Manitowoc Grove GRT9165 Service Manual

1-7
Published 10-01-2020 Control # 699-00
GRT9165 SERVICE MANUAL INTRODUCTION
1
GROVE
120 t (134 USt) Hookblock (8 sheave) - in
stowage tray
469.90 (185.00) 1180 (2601) 1109 (2444) 71 (157)
100 t (112 USt) Hookblock (7 sheave) - in
stowage tray
469.90 (185.00) 1140 (2513) 1071 (2362) 68 (151)
75 t (83 USt) Hookblock (5 sheave) - in
stowage tray
469.90 (185.00) 1070 (2359) 1006 (2217) 64 (142)
45 t (50 USt) Hookblock (3 sheave) - in
stowage tray
469.90 (185.00) 770 (1698) 724 (1596) 46 (102)
26 t (29 USt) Hookblock (1 sheave) - in
stowage tray
469.90 (185.00) 323 (712) 303 (669) 20 (43)
Add to Basic Unit Weight - Optional Equipment
360° Swing Lock 174.45 (68.68) 34 (75) 12 (26) 0 (49)
Rubber Mat in Front Storage Tray 466.09 (183.50) 26 (58) 24 (54) 2 (4)
Cold Weather Package - Carrier (-29°) 116.84 (46.00) 67 (147) 15 (34) 51 (113)
Cold Weather Package - Carrier (-40°) 182.88 (72.00) 113 (250) 41 (91) 72 (159)
Cold Weather Package - S/S 149.05 (58.68) 38 (84) 11 (25) 27 (59)
Driver 218.44 (86.00) 113 (250) 49 (109) 64 (141)
Substitutions and Removals from Basic Unit Weight
REM: Front Outrigger Box and Beam
Assembly
662.99 (261.02) 3955 (-8720) -5245 (-11563) 1290 (2843)
REM: Rear Outrigger Box and Beam
Assembly
-262.99 (-
103.54)
-3955 (-8720) 2081 (4587) -6036 (-13307)
REM: Titan 26.5 x 25 (44) tires (for travel) 167.64 (66.00) -4267 (-9408) -1431 (-3154) -2837 (-6254)
SUB: Export Engine (Non Certified) 93.98 (37.00) -107 (-236) -20 (-44) -87 (-192)
REM: Main Hoist cable (294 m (965 ft) of
19 mm (3/4 in) 35x7)
-127.30 (-50.12) -567 (-1250) 144 (318) -711 (-1568)
REM: Aux Hoist cable (233 m (764 ft) of
19 mm (3/4 in) 35x7)
-213.51 (-84.06) -450 (-992) 192 (424) -642 (-1416)
Add: Lift Cylinder Travel Support 505.46 (199.00) 59 (129) 59 (130) 0 (-1)
Description
CG To CL Rear
Bogie cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
