Manitowoc Grove GRT9165 Service Manual

INTRODUCTION GRT9165 SERVICE MANUAL
1-6
Published 10-01-2020 Control # 699-00
Table 1-1 Axle Weight Distribution Table
Description
CG To CL Rear
Bogie cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Basic Unit
Maximum Axle Allowable at 16 km/h
(10 mph)
33113 (73000) 66225 (146000)
Maximum Axle Allowable at 4 km/h
(2.5 mph)
43727 (96400) 87454 (192800)
Standard Carrier Assembly + All Fluids +
Outrigger Boxes and Beams
177.29 (69.80) 32235 (71065) 11430 (25199) 20805 (45866)
Superstructure Assembly w/both hoists +
294 m (965 ft) main hoist cable + 233 m
(764 ft) aux hoist cable
31.52 (12.41) 8411 (18543) 530 (1169) 7881(17374)
Removable Counterweight -164.64 (-64.82) 25760 (56790) -8482 (-18700) 34242 (75490)
Boom Assembly with Lift Cylinder Upper Pin
& Pivot Pin
610.41 (240.32) 15662 (34528) 19120 (42153) -3459 (-7625)
Lift Cylinder & Lower Shaft 485.55 (191.16) 1402 (3091) 1362 (3002) 40 (89)
Complete Basic Machine: 13.7 m - 62.5 m
(44.9 ft - 205 ft) 6-Section Boom, Cummins
QSB6.7L Tier 4F Final Engine, 26. 5x 25 (44
ply) Titan Tires, Main Hoist with 294 m
(965 ft) of 19 mm (3/4 in) 35 x 7 cable, Aux
Hoist with 233 m (764 ft) of 19 mm (3/4 in)
35x7 cable, Full Fuel and Hydraulic Oil
148.62 (58.51) 83470 (184017) 23960 (52822) 59510 (131195)
Add To Basic Unit Weight - Boom Extensions
10.9 to 17.8 m (35.7 to 58.4 ft) Manually
Offsetable Boom Extension
840.21 (330.79) 1658 (3655) 2786 (6142) -1128 (-2487)
10.9 to 17.8 m (35.7 to 58.4 ft) Hydraulic
Offsetable Boom Extension
851.10 (335.08) 1759 (3878) 2994 (6601) -1235 (-2723)
Extension Carrier Brackets - Manual
Extension
712.01 (280.32) 154 (340) 220 (484) -65 (-144)
Extension Carrier Brackets - Hydraulic
Extension
750.11 (295.32) 133 (294) 200 (441) -67 (-147)
Hose Reel for Hydraulic Extension 986.33 (388.32) 216 (476) 426 (939) -210 (-463)
Aux Boom Nose - Installed 1369.06
(539.00)
195 (430) 534 (1177) -339(-747)
8 m (26.2 ft) Insert - Manual Boom Extension
(not included in weight)
620 (1367)
8 m (26.2 ft) Insert - Hydraulic Boom
Extension (not included in weight)
631 (1391)
Add to Basic Unit Weight - Rigging Equipment
11 t (12 USt) Overhaul Weight - tied to O/R
Box
787.40 (310.00) 380 (838) 599 (1320) -219 (-482)
11 t (12 USt) Overhaul Ball - tied to O/R Box 787.40 (310.00) 378 (833) 595 (1312) -217 (-479)
