Manitowoc Grove GRT9165

POWER TRAIN GRT9165 SERVICE MANUAL
7-14
Published 10-01-2020 Control # 699-00
Exhaust System - Non-Certified Engine
FIGURE 7-13
7
1
2
3
5
4
6
6
8
11
10
9
12
1 Jam Nut
2 Clamp, V-Band
3 Gasket
4 Flex Coupler
5 Clamp, V-Band
6 Clamp, Slip Joint
7 Muffler
8 Clamp, Mounting Band
9 Muffler Clamp
10 Nut
11 Tail Pipe Tube
12 Tail Pipe
10189
10190
