FW105 Configuration
The FW105 function is governed by several modules. All the functional module units are shown in Table 2:
Table 2 FW105 Module Units
Module Units Type
Qty.
Fixed/
Configurable
Notes
AMI, FW202
(Advanced Machine Interface)
1
Fixed
Includes: CPU board, LCD, Keypad, LED, Buzzer, etc.
PSU, FW390
(Power Supply Unit)
1
Fixed
120V/240VAC selectable
MFU, FW301
(Multi-functional Unit)
1
Fixed
4 NACs
1 SLC supports 252 devices
4 Relay Outputs
1 Class X/DCLC network circuit
1 Class B/DCLB network circuit
LDU, FW261A
(LED Display Unit)
1
Fixed
30zones (2 LEDs and 1 key per zone) for alarm/
trouble events display & control
NOU, FW338
(Notification Output Circuit)
0 - 1
Configurable
4 NACs
ISU, FW852
(Isolator Unit)
0 - 2
Configurable
4 SLC isolator circuits
