Appendix-B: Wire Selection Guide
SLC Wire Selection Guide
Maximum Loop Current = 100mA@NSB, 220mA@Alarm
Maximum Loop Capacitance = 0.1F
Table 15 Addressable Loop Wiring
Wire Gauge
Maximum Wiring Run to Last Device
(AWG)
Wire
Resistance
（Ω/km）
Maximum current
90mA
Maximum current
150mA
Maximum current
220mA
ft
m
ft
m
ft
m
12
5.31
15099
4603
9060
2762
6177
1883
13
6.69
11985
3654
7191
2192
4903
1495
14
8.45
9488
2893
5693
1736
3882
1183
15
10.6
7564
2306
4538
1384
3094
943
16
13.5
5939
1811
3563
1086
2430
741
17
16.3
4919
1500
2951
900
2012
613
18
21.4
3747
1142
2248
685
1533
467
