Installation and Operation Manual
53
Appendix-C: Quantities of Notification Appliances
Table 18 lists the maximum number of notification appliances per NAC and SLC in the worst case scenario for
Synchronization system.
Table 18 Maximum Numbers of Notification Appliances per NAC
Model No.
Description
Maximum number per NAC
FW971R/FW971W/FW971GR/FW971GW
Horn
110
FW962R / FW962W/FW962GR/FW962GW
Multi-candela Horn Strobe
33
FW982R / FW982W/FW982GR/FW982GW
Multi-candela Strobe
33
FW972M
Mini Horn
110
FW963AR / FW963AW / FW963AGR /
FW963AGW
Addressable Horn Strobe
30
FW973AR / FW973AW / FW973AGR /
FW973AGW
Addressable Horn
35
FW983AR / FW983AW / FW983AGR /
FW983AGW
Addressable Strobe
40
Table 19 Maximum Numbers of Addressable Notification Appliances per SLC
Model No.
Description
Maximum number per SLC
FW963AR / FW963AW / FW963AGR /
FW963AGW
Addressable Horn Strobe
50
FW973AR / FW973AW / FW973AGR /
FW973AGW
Addressable Horn
50
FW983AR / FW983AW / FW983AGR /
FW983AGW
Addressable Strobe
50
If these 3 types of notification appliances are mixed in the same circuit, the total
current of the circuit must be <= 2 Amperes.
