Installation and Operation Manual
7
Specifications and Features
The specifications and features of the FW105 Control Panel are described in Table 3.
Table 3 FW105 Control Panel Specifications
General
Digital signal processor-based design, fully configurable from front panel with
password protection
Environmental
Operating temperature: 32 - 120F (0 - 49C)
Relative humidity: Up to 93% @ 90F (32C)
To be installed in normal dry indoor environment only
Primary Supply
110 - 120 VAC 60Hz (5.3A), or
220 - 240 VAC 50Hz (2.6A)
Secondary Power
Supply
Two 12V in series lead-acid batteries
Charging capacity: 40 AH
Power Outputs
Internal power supply for
AMI (Advanced Machine Interface)
MFU (Multi-functional Unit)
NOU (Notification Output Unit)
ISU (Isolator Unit)
LDU (LED Display Unit)
Two auxiliary power supplies
Non-Resettable/Resettable Power Output (configurable)
Power limited output current combined for both aux outputs: 510mA in total
(normal standby), 1.0A in total (alarm)
Power Factor Rating: 0.35
Special application: Compatible devices are the Annunciator Model FW121 /
FW121C /FW122W / FW122R / FW122CW / FW122CR / FW123 / FW123C /
FW129 / FW129C and Supervised Output Module Model FW821 / FW821H.
Class E or
CLASS B when powering annunciator models FW121 / FW121C /FW122W / FW122R /
FW122CW / FW122CR / FW123 / FW123C / FW129 / FW129C/FW821.
SLC
(Signaling Line Circuit)
Class A/DCLA or Class B/DCLB circuit
252 addresses: detectors and modules max
Output voltage range: 19.4V ~ 27.5V
Maximum normal standby current: 100mA
Maximum alarm current: 220mA
Max. line capacitance = 0.1 F
Max. line resistance = 10 Ω per line
