Maple Armor FW105 - Page 14

Installation and Operation Manual
8
NAC
(Notification Appliance
Circuits)
 24 VDC
 Class A / Class B circuits
 Maximum Current: 2A per NAC circuit
 A total of 8 circuits supported, with addition of 1 NOU, total power available 10A
 Bell code: Temporal 3 (for conventional appliance), Continuous (for addressable
appliance)
 Bell code: Gentex, Temporal (not UL approved)
 Panel supports one of the following:
One regulated circuit only or
Up to eight special application circuits. Refer to Table 18 for specific
appliances/devices
 Max line loss: 1.8 V
Relays Output
 4 programmable relays
 Default status: Alarm, Supervisory, Trouble, Monitor
 Form C Contact
 Contact Rating: 5A 30VDC; 5A 120VAC
 Power Factor Ration:0.35
Network Circuit
 One Class B/DCLB circuit & One Class X/DCLC circuit
 For up to 110 panels or remote annunciators connection on Class B/DCLB
 For up to 32 panels connection on Class X/DCLC
 Communications protocol: CAN
 Max. line capacitance = 0.05 F
 Max. line resistance = 25 Ω
ISU
(Isolator Unit)
 8 SLC isolator circuits supported with the addition of 2 ISU
 Class B/DCLB circuit
Recommended Testing
impendence
 6.6 kΩ for ground fault
 10 MΩ for open
 0.1 Ω for short
